Features
Accuracy guarantees by P.I.D controller within 0.1%
The shutter attached on the over size hopper.
The calibrating gate is designed for easy access.
Direct current non-carbon brush motor is used for maintenance free.
Equipped with indicator and alarm for the motor overload,overheat and lack phase.
Contact unit with the material is made from the stainless steel.
No-tools are required for clean and maintenance.
Specification
Specification SCM-16 SCM-20 SCM-26
Amature Voltage AC 220V +10% or -10%
Frequency 50HZ/60HZ
Motor Power 40W
Motor Speed 300-3000PPM
Gear Ratio 1:30
Screw Diameter(mm) 16 20 26
Outpur Capacity(kg/hr) 0.5-4.5 4-35 10-80
Hopper Volume(L) 10
Temperature 0-45oC
Weight(Kg) 15
