 SPECIFICATION |
| Model |
Motor Power |
Cylinder |
Speed |
Act Capacity |
Working Pressure |
Tank Capacity |
Dimension |
Weight |
| KW/HP |
Cyl/Dia (mm*pcs) |
Stroke (mm) |
rpm |
m3/min |
Mpa |
m3 |
mm |
Kg |
| HTA-100XI |
7.5/10 |
100*2/55*1 |
70 |
800 |
0.63 |
3.0 |
0.22 |
1490*600*1160 |
430 |
| HTA-100XII |
7.5/10 |
100*2/55*1 |
70 |
880 |
0.7 |
2.5 |
0.22 |
1490*600*1160 |
430 |
| HTA-120XI |
11/15 |
120*2/65*1 |
80 |
800 |
1.0 |
3.0 |
0.39 |
1740*677*1382 |
640 |
| HTA-120XII |
11/15 |
120*2/65*1 |
80 |
880 |
1.1 |
2.5 |
0.39 |
1740*677*1382 |
640 |
| HTA-120-A |
11/15 |
120*2/80*1 |
80 |
800 |
1.2 |
1.5 |
0.37 |
1740*677*1382 |
635 |
| HTA-100XD |
7.5/10 |
100*2/55*1 |
70 |
800 |
0.63 |
3.0 |
/ |
1150*470*730 |
285 |
| HTA-120XD |
11/15 |
120*2/65*1 |
80 |
800 |
1.0 |
3.0 |
/ |
1370*700*850 |
375 |
| SSA-120 |
15/20 |
120*2/100*1/55*1 |
80 |
800 |
1.2 |
4.0 |
0.42 |
1830*656*1418 |
740 |
| 4xSSA-120 |
4*15/4*20 |
120*4*2/100*4*1/55*4*1 |
80 |
800 |
4.9 |
4.0 |
/ |
1950*1950*1590 |
2250 |
| 4xHTA120X |
4*11/4*15 |
120*4*2/65*4*1 |
80 |
800 |
4.0 |
3.0 |
/ |
1880*1820*1380 |
2050 |
| STA-155 |
15/20 |
155*1/100*1/55*1 |
/ |
800 |
1.2 |
3.0 |
0.40 |
1810*725*1440 |
610 |
|
|
